Rubber Sheets / Rolls
:
|
NR / SBR RUBBER SHEETS & ROLLS |
|
|
. |
|
DESCRIPTION : |
|
NR / SBR blend rubber sheets / rolls are used in
the commercial and industrial applications. This
specifically designed rubber material is
long-lasting that is suitable for operational
use which provides excellent mechanical
properties like high resilience, low compression
set, high resistance to cut, tear & abrasion &
also offers resistance to many acids, alkalis &
salts. The operation temperature range is
(-20°C to +80°C). It is available in wide range
of hardness from 40 Shore A to 80 Shore A. It
has very good physical properties like Tensile
strength, wear & tear properties, Abrasion
resistance.
|
|
APPLICATIONS : |
|
NR / SBR Rubber
sheets / rolls are used for wide range of
applications like skirt board, bridge bearing,
gasket for high pressure packing, heavy weight
machinery packing, Para-quality for sand/shot
blasting machinery & used as shock absorber. NR
/ SBR Rubber sheets/rolls can be used as shelf
liner; workstation table liner and work area
rubber lining that can withst and moderate
chemicals & alkaline solutions. These sheets can
also be used for anti abrasion lining for
material handling machinery in mines alike
industries
|
|
PROPERTY : |
|
Excellent
resistance to inorganic chemicals, water, air &
heat up to 80°C. Poor resistance to Ozone, UV,
Sunlight, oil & solvents & organic chemicals.
|
|
 |
|
|
 |
|
PHOTO GALLERY |
|
|
CATALOG |
GRADES |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Elongation (%) |
|
 |
BNS-1240 |
1.20 |
40 |
80 |
600 |
|
|
BNS-1345 |
1.30 |
45 |
90 |
500 |
|
|
BNS-1450 |
1.40 |
50 |
70 |
450 |
|
|
BNS-1565 |
1.50 |
65 |
60 |
400 |
|
|
BNS-1670 |
1.60 |
70 |
50 |
300 |
|
|
|
|
PRODUCT DIMENSIONS |
|
Rotocure Finish |
|
Plate Finish |
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 10, 20,
30 |
3 to 12 |
|
Finish |
Smooth /
Texture Impression |
|
|
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 2.4 |
3 to 25 |
|
1.0 x 2.0 |
3 to 25 |
|
|
|
|
|
|
MANUFACTURING TOLERANCES |
|
THICKNESS |
WIDTH |
LENGTH |
HARDNESS |
DENSITY |
|
+ / - 0.3mm or
10% whichever is higher |
+ / - 2% |
+ / - 5% |
+ / - 5 |
+ / - 0.05 |
|
|
|
|
STORAGE OF PRODUCTS |
|
Do not expose
rubber sheet to direct sunlight, sheets away from heat source,
preferably in dark, air ventilated room will help give longer life &
optimum properties |
|
Do not
remove polythene packing before use to prevent it from exposure of
atmospheric oxygen, ozone & polluted air. Do not store rubber sheet
rolls in open, even after covering it with tarpaulin to protect from air
& rain. Always keep rolls in vertical position ONLY |
|
Keep
rolls away from solvent, oil & fuel storage. Do not use hooks while
loading/unloading the rolls. Inspect sheet for smooth surface & hardness
(with rubber hardness tester).. |
|
|
|
