Rubber Sheets / Rolls
:
|
EPDM RUBBER SHEETS & ROLLS |
|
|
. |
|
DESCRIPTION : |
|
EPDM rubber sheet /
roll is very good weatherproof quality that
makes highly recommended for the outdoor use,
These sheets resist to oxidation, UV rays,
Ozone, weathering & low temperature flexibility.
The operating temperature range is from (-40°C
to +130°C). EPDM rubber sheets / rolls are
stable for long time due to its inert structure
|
|
APPLICATIONS : |
|
EPDM rubber sheets are highly used for
industrial & outdoor application like weather
strips, drinking water applications, rain water
sealing, protection against sunlight & heat
gaining as a roofing membrane & acid resistance
applications. Also useful as a liner in
pulverizing system.
|
|
PROPERTY : |
|
Very good resistance to water & water-based
chemicals withstand temperature up to 130°C.
Very good weathering resistance. Good resistance
to mild acids, liquid fertilizer & break fluids.
No resistance to oil & oil based products.
|
|
 |
|
|
 |
|
PHOTO GALLERY |
|
|
100%
EPDM RUBBER SHEET : BLACK |
|
CATALOG |
GRADES |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Eb
(%) |
|
 |
BEP-1155 |
1.1 |
55 |
70 |
500 |
|
|
BEP-1260 |
1.2 |
60 |
80 |
400 |
|
|
BEP-1365 |
1.3 |
65 |
100 |
300 |
|
|
BEP-1470 |
1.4 |
70 |
70 |
250 |
|
|
|
|
COMMERCIAL
GRADE EPDM RUBBER SHEET |
|
CATALOG |
GRADES |
EPDM (%) |
DENSITY (g/cc) |
HARDNESS (SH–A) |
TENSILE (Kg/cm2) |
Eb(%) |
|
|
BEPNR-50 |
50 |
1.5 |
65 |
50 |
250 |
|
|
|
|
PRODUCT DIMENSIONS |
|
Rotocure Finish |
|
Plate Finish |
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 10, 20,
30 |
3 to 12 |
|
Finish |
Smooth /
Texture Impression |
|
|
|
SIZE (Mtrs) |
THICKNESS (MM) |
|
1.2 x 2.4 |
3 to 25 |
|
1.0 x 2.0 |
3 to 25 |
|
|
|
|
|
|
MANUFACTURING TOLERANCES |
|
THICKNESS |
WIDTH |
LENGTH |
HARDNESS |
DENSITY |
|
+ / - 0.3mm or
10% whichever is higher |
+ / - 2% |
+ / - 5% |
+ / - 5 |
+ / - 0.05 |
|
|
|
|
RECOMMENDATIONS REGARDING STORAGE AFTER RECEIPT |
|
Store
according to DIN 7716 standards. Products must be stored in cool, dry &
dark places |
|
Avoid contact
with hydrocarbons, solvents, acids & alkalies. |
|
If there is
any doubt about the condition of sheet/roll, they should be retested
before putting into service. |
|
Products
should be issued in the order of their date of manufacture. |
|
|
|
